SUNMI MINI AP

SUNMI MINI APSmall size. Huge reach. Connect everywhere.

MINI AP is a wireless access point product featuring SUNMI Hyper Wi-Fi technology.

Simply Add MINI AP to Your Current Network Solution

Simply Add MINI AP to
Your Current Network Solution

Connect Everywhere

Huge ReachSignal coverage extends to every corner of your factory warehouse.

Better PenetrationPenetrate walls for enhanced front and back-of-house communication.

High StabilitySeamless performance even amidst the electrical interference in nightclubs.

Farther, and More Stable

The Distance Other Wi-Fi Signals Can TravelBetter Wall Penetration

1KM

Maximum RangeThe Signal Can Cover a 2000m² Store

90%

Roaming TimesStable Connection, Anti-interference

Terminals Connected Simultaneously

SUNMI Hyper Wi-Fi

Learn More

*Data from SUNMI Lab. Distance data is straight-line communication distance collected from tests in open environments.

Palm Size, Powerful Connectivity76 * 76 * 19mm, 73g

Plug and Play

Connect it with a terminal using a Type-C USB cable both for power and networking.*This feature requires a software update.

Switch easily between the AP/Transmitter Mode and the Client/Receiver Mode.

AP/Transmitter Mode

Client/Receiver Mode

Switch easily between the AP/Transmitter Mode and the Client/Receiver Mode.

AP/Transmitter Mode

Client/Receiver Mode

One-press Network Pairing

AP/Transmitter ModeClient/Receiver Mode

Cloud Management Made Easy

Get a comprehensive overview of all device statuses locally on the Web platform.

Configure on DMP remotely for seamless offline store use.

Manage MINI AP on SUNMI Assistant APP.*SUNMI Assistant APP supports both iOS and Android OS.

Manage MINI AP with SUNMI OS.*Needs to be used with SUNMI OS devices running a specified ROM version.

Usage Instructions

Use Hyper Wi-Fi with MINI APSupported by SUNMI 2nd gen desktop terminals kiosks, IoT products.

SUNMI MINI AP Tech Specs

Product Model

FW020

Linux

Wireless Protocols

802.11ah

Wireless Frequency

Sub 1GHz

Antenna

A built-in antenna

Wireless Security Protocols

Supports up to WPA3

Wireless Mode of Operation

AP (Transmiter Mode)
Client (Receiver Mode)

Power Indicator

Flashing white:
The system is starting
Solid white:
The system is working normally

Wireless Indicator

AP (Transmiter Mode)
Solid blue: Wireless is working properly
Flashing blue: Waiting for the client to be connected

Client (Receiver Mode)
Solid green: The AP is connected and the signal is good
Flashing green: Searching AP signals
Solid orange: The AP is connected and the signal is poor
Off: The AP cannot be connected

Wired Network

1 x 10/100Mbps LAN port

Power Adapter

DC 5V/2A (Type-C USB)

Buttons

1 Reset button
1 wireless network pairing button
1 mode toggle switch

Total Weight

73g

Operating Environment

Operating temperature: -10°C to 40°C
Operating humidity: 10%~90% RH (non-condensing)

Storage Environment

Storage temperature: -40°C to 70°C
Storage humidity: 10%~90% RH (non-condensing)

Accessories

1* user guide
1* network cable
1* Type-C USB cable
1* piece of 3M adhesive backing

Dimensions (L*W*H)

76*76*19mm
